Streamlite Floor Plans

Show:
Filter by:

Streamlite Ultra Lite Floor Plans

Model TypeGulf Stream Streamlite 23CB
23CB
Gulf Stream Streamlite 235RB
235RB
Gulf Stream Streamlite 265CB
265CB
Gulf Stream Streamlite 267RL
267RL
Gulf Stream Streamlite 275BB
275BB
Key Specifications
Length27'1"27'4"31'0"32'2"32'5"
Width96"96"96"96"96"
Exterior Height11'2"11'2"11'2"11'2"11'2"
Interior Height80"80"80"80"80"
Additional Specs
Dry Weight5,4964,825TBD6,043TBD
Hitch Weight860596TBD660TBD
Net Carrying Capacity2,3642,775TBD3,417TBD
Fresh Water3636363636
Grey Tank2929292929
Black Tank2929292929
Furnace20,000 BTU20,000 BTU30,000 BTU30,000 BTU30,000 BTU
Water Heater6 Gal6 Gal6 Gal6 Gal6 Gal
LP Tank2 x 20 lbs.2 x 20 lbs.2 x 20 lbs2 x 20 lbs.2 x 20 lbs
Model TypeGulf Stream Streamlite 280TB
280TB
Gulf Stream Streamlite 281DB
281DB
Gulf Stream Streamlite 293RK
293RK
Gulf Stream Streamlite 295DC
295DC
Gulf Stream Streamlite 296TS
296TS
Key Specifications
Length34'6"34'1"34'6"35'10"38'2"
Width96"96"96"96"96"
Exterior Height11'4"11'4"11'4"11'6"11'6"
Interior Height80"80"80"80"80"
Additional Specs
Dry Weight6,730TBD6,6187,323TBD
Hitch Weight760TBD700960TBD
Net Carrying Capacity2,770TBD2,8822,437TBD
Fresh Water3636363636
Grey Tank2929292929
Black Tank2929292929
Furnace30,000 BTU30,000 BTU30,000 BTU30,000 BTU30,000 BTU
Water Heater6 Gal6 Gal6 Gal6 Gal6 Gal
LP Tank2 x 20 lbs.2 x 20 lbs.2 x 20 lbs.2 x 20 lbs2 x 20 lbs.

Special Value Trailer Floor Plans

Model TypeGulf Stream Streamlite 18RBD
18RBD
Gulf Stream Streamlite 19FMB
19FMB
Gulf Stream Streamlite 22UDL
22UDL
Key Specifications
Length21'1"23.3"25'5"
Width96"96"96"
Exterior Height10'4"10'6"10'6"
Interior Height80"80"80"
Additional Specs
Dry Weight3,2883,4593,775
Hitch Weight320370420
Net Carrying Capacity7451,3113,665
Fresh Water295454
Grey Tank333333
Black Tank333333
Furnace16,000 BTU16,000 BTU20,000 BTU
Water Heater6 Gal6 Gal6 Gal
LP Tank2 x 20 lbs.

LE Series Floor Plans

Model TypeGulf Stream Streamlite 24RBS
24RBS
Gulf Stream Streamlite 25BHS
25BHS
Gulf Stream Streamlite 28CRB
28CRB
Gulf Stream Streamlite 28BBS
28BBS
Key Specifications
Length24'8"27'2"30'3"31'2"
Width96"96"96"96"
Exterior Height10'6"11'0"10'11"11'0"
Interior Height80"80"80"11'0"
Additional Specs
Dry Weight4,7005,0406,1205,820
Hitch Weight530540520640
Net Carrying Capacity2,3402,0001,4001,220
Fresh Water35353535
Grey Tank28282828
Black Tank28282828
Furnace20,000 BTU20,000 BTU30,000 BTU30,000 BTU
Water Heater6 Gal6 Gal6 Gal6 Gal
LP Tank2 x 20 lbs.2 x 20 lbs.2 x 20 lbs.2 20 lbs.
