Ameri-Lite Floor Plans

Show:
Specifications are approximate and subject to change.
Check the label in your unit for actual weights and capacities.
Filter by:

Ultra-Lite Floor Plans

Gulf Stream Ameri-Lite 20RBS
20RBS | Overall Weight: 4,360 lbs.

Gulf Stream Ameri-Lite 22RSD
22RSD | Overall Weight: 4,064 lbs.

Gulf Stream Ameri-Lite 236RL
236RL | Overall Weight: 5,140 lbs.

Gulf Stream Ameri-Lite 238RK
238RK | Overall Weight: 4,815 lbs.

Gulf Stream Ameri-Lite 240RK
240RK | Overall Weight: 5,250 LBS lbs.

Gulf Stream Ameri-Lite 241RB
241RB | Overall Weight: 4,031 lbs.

Gulf Stream Ameri-Lite 248BH
248BH | Overall Weight: 3,899 lbs.

Gulf Stream Ameri-Lite 24RLS
24RLS | Overall Weight: 5,050 lbs.

Gulf Stream Ameri-Lite 26BHG
26BHG | Overall Weight: 4,930 lbs.

Gulf Stream Ameri-Lite 268BH
268BH | Overall Weight: 5,177 lbs.

Gulf Stream Ameri-Lite 269BH
269BH | Overall Weight: 5,460 lbs.

Gulf Stream Ameri-Lite 275FBG
275FBG | Overall Weight: 5,100 lbs.

Gulf Stream Ameri-Lite 274QB
274QB | Overall Weight: 6,230 lbs.

Gulf Stream Ameri-Lite 279BH
279BH | Overall Weight: 6,210 lbs.

Gulf Stream Ameri-Lite 292RBH
292RBH |

Super Lite Floor Plans

Gulf Stream Ameri-Lite 14RE
14RE | Overall Weight: 2,780 lbs.

Gulf Stream Ameri-Lite 177BH
177BH | Overall Weight: 2,810 lbs.

Gulf Stream Ameri-Lite 178RB
178RB | Overall Weight: 2,920 lbs.

Gulf Stream Ameri-Lite 189DD
189DD | Overall Weight: 2,996 lbs.

Gulf Stream Ameri-Lite 199DD
199DD | Overall Weight: 3,100 lbs.

Gulf Stream Ameri-Lite 197BH
197BH | Overall Weight: 3,663 lbs.

Gulf Stream Ameri-Lite 199RK
199RK | Overall Weight: 3,520 lbs.

Gulf Stream Ameri-Lite 19RD
19RD | Overall Weight: 3,552 lbs.

Gulf Stream Ameri-Lite 192DS
192DS | Overall Weight: 3,910 lbs.

Ultra-Lite Floor Plans

Model TypeGulf Stream Ameri-Lite 20RBS
20RBS		Gulf Stream Ameri-Lite 22RSD
22RSD		Gulf Stream Ameri-Lite 236RL
236RL		Gulf Stream Ameri-Lite 238RK
238RK		Gulf Stream Ameri-Lite 240RK
240RK
Key Specifications
Length22'11"25'7"28'1"28'6"26'3"
Width8'8'8'8'8"
Exterior Height11'2"10'9"11'3"11'1"11'1"
Interior Height6'8"6'8"6'8"6'8"80"
Additional Specs
Dry Weight4,3604,0645,1404,8155,250 LBS
Hitch Weight400530930640650 LBS
Net Carrying Capacity3,0273,4662,7902,8652,400 LBS
Fresh Water3623232336 GAL
Grey Tank2936363636 GAL
Black Tank2936363636 GAL
Furnace20,000 BTU20,000 BTU20,000 BTU20,000 BTU20,000 BTU
Water HeaterTanklessTanklessTanklessTanklessTankless
LP Tank2 x 20 lbs2 x 20 lbs2 x 202 x 20 lbs2 Ea @ 20 LBS
Model TypeGulf Stream Ameri-Lite 241RB
241RB		Gulf Stream Ameri-Lite 248BH
248BH		Gulf Stream Ameri-Lite 24RLS
24RLS		Gulf Stream Ameri-Lite 26BHG
26BHG		Gulf Stream Ameri-Lite 268BH
268BH
Key Specifications
Length27'4"26'7"28'10"29'11"29'6"
Width8'8'8'8'8'
Exterior Height9'10"10'4"11'1"10'9"11'1"
Interior Height6'8"6'8"6'8"6'8"6'8"
Additional Specs
Dry Weight4,0313,8995,0504,9305,177
Hitch Weight478500580590660
Net Carrying Capacity3,4873,6014,3302,6602,483
Fresh Water3023233623
Grey Tank3636363736
Black Tank3636363736
Furnace20,000 BTU20,000 BTU20,000 BTU25,000 BTU20,000 BTU
Water HeaterTanklessTanklessTanklessTanklessTankless
LP Tank2 x 20 lbs2 x 20 lbs2 x 20 lbs.2 x 20 lbs2 x 20 lbs
Model TypeGulf Stream Ameri-Lite 269BH
269BH		Gulf Stream Ameri-Lite 275FBG
275FBG		Gulf Stream Ameri-Lite 274QB
274QB		Gulf Stream Ameri-Lite 279BH
279BH		Gulf Stream Ameri-Lite 292RBH
292RBH
Key Specifications
Length29'11"30'0"32'6"32'6"
Width8'8'8'8'
Exterior Height11'1"10'9"11'1"11'1"
Interior Height6'8"6'8"6'8"6'8"
Additional Specs
Dry Weight5,4605,1006,2306,210
Hitch Weight670710840810
Net Carrying Capacity2,2102,6101,6101,600
Fresh Water23362323
Grey Tank37373737
Black Tank36373737
Furnace20,000 BTU25,000 BTU20,000 BTU20,000 BTU
Water HeaterTanklessTanklessTanklessTankless
LP Tank2 x 20 lbs2 x 20 lbs.2 x 20 lbs2 x 20 lbs

Super Lite Floor Plans

Model TypeGulf Stream Ameri-Lite 14RE
14RE		Gulf Stream Ameri-Lite 177BH
177BH		Gulf Stream Ameri-Lite 178RB
178RB		Gulf Stream Ameri-Lite 189DD
189DD		Gulf Stream Ameri-Lite 199DD
199DD
Key Specifications
Length15'10"20'11"20'11"20'11"20'11"
Width7'6"8'8'8'8'
Exterior Height10'3"10'4"10'4"10'4"10'4"
Interior Height6'8"6'8"6'8"6'8"6'8"
Additional Specs
Dry Weight2,7802,8102,9202,9963,100
Hitch Weight300330360350360
Net Carrying Capacity1,0201,0201,080854760
Fresh Water2323232323
Grey Tank3636363636
Black Tank3636363636
Furnace20,000 BTUElec. HeatElec. Heat20,000 BTU20,000 BTU
Water HeaterTanklessTanklessTanklessTanklessTankless
LP Tank20 lbs20 lbs2020 lbs20 lbs.
Model TypeGulf Stream Ameri-Lite 197BH
197BH		Gulf Stream Ameri-Lite 199RK
199RK		Gulf Stream Ameri-Lite 19RD
19RD		Gulf Stream Ameri-Lite 192DS
192DS
Key Specifications
Length22'2"22'2"23'1"23'2"
Width8'8'8'8'
Exterior Height10'8"10'8"10'8"10'6"
Interior Height6'8"6'8"6'8"6'8"
Additional Specs
Dry Weight3,6633,5203,5523,910
Hitch Weight638490390390
Net Carrying Capacity1,3951,3701,2381,238
Fresh Water23232323
Grey Tank36363636
Black Tank36363636
Furnace20,000 BTU20,000 BTU20,000 BTU20,000 BTU
Water HeaterTanklessTanklessTanklessTankless
LP Tank20 lb.20 lbs20 lbs20 lbs
